Incoloy®Alloy 20(UNS N08020) is an austenitic nickel-iron-chromium alloy with additions of copper and molybdenum. The nickel content makes Alloy 20 resistant to chloride-ion stress-corrosion cracking. Copper and molybdenum give resistance to reducing environments. The molybdenum content also provides good resistance to pitting and crevice corrosion. The chromium gives resistance to oxidizing environments such as nitric acid. The addition of niobium reduces the effect of carbide precipitation during welding, thus increasing the alloy’s resistance to intergranular corrosion.
Product Description
| Item | Incoloy 020 Plate |
| Standard | ASTM B462 ASTM B472, ASTM B473, ASME SB 472, ASME SB 473, ISO 9723, ISO 9724, ISO 9725, DIN 17752-17754 |
| Thickness | 2.5-100mm or as required |
| Width | 0.05-2mm or as required |
| Length | 0.1-6m or as requied |
| Finish | No.1, Bright, Oxidation |
| Property |
|
Chemical Composition(%)
| Ni | Fe | Cr | Mo | Cu |
| 32-38 | 29.9-44 | 19-21 | 2-3 | 3-4 |
| Mn | Si | C | P | S |
| <=2 | <=1 | <=0.07 | <=0.045 | <=0.035 |
Application
Synthetic rubber manufacturing equipment
Processing of pharmaceuticals, plastics and organic and heavy chemicals
Tanks, piping, heat exchangers, pumps, valves, and other process equipment
production of gasoline, solvents, explosives, inorganic and organic chemicals, pharmaceuticals, and food and synthetic materials
heat exchangers, process piping and pickling equipment
Chemical process piping, reactor vessels
Bubble caps
Food and dye production
